76
[5.1] Bar-code reading test
Selecting "1:BARCODE" on the TEST menu calls up the screen
shown at left.
Actually read bar codes with the BHT and check the read data
displayed on the LCD.
⇓
Upon completion of bar-code reading, the BHT beeps, turns on the
indicator LED in green, and displays the read data together with the
barcode type and the number of digits.
To return to the TEST menu, press the C key.
Listed below is a table showing the relationship between the bar-code types and the identifier letters to
be displayed on the LCD.
Bar-code Type ID Letters
EAN-13, UPC-A
EAN-8
UPC-E
Standard 2of5 (STF)
Interleaved 2of5 (ITF)*
A
B
C
H
I
Codabar (NW-7)
Code 39
Code 93
Code 128
EAN-128
N
M
L
K
W
* The BHT can read only those ITF bar codes having 4 digits or more in length.
Bar-code type
Number of digits of the bar code
Data
