Installation LAN Integration
Connection of a door opener and entrance intercom system (Siedle)
LAN Integration
Using the LAN port (Ethernet port),
you can integrate the OpenCom 100
into your company network (LAN,
Local Area Network), and thus use it
for amongst other purposes as an IP
router for accessing the Internet.
In addition you can use this port to
connect you LAN to a remote LAN
(please see also LAN-to-LAN Link
starting on page 46).
The second LAN port of the Open-
Com 120 enables networking to an
OpenCom 110 or an OpenCom 120.
Door bell
Siedle
PVG
402-0
To
c1
Ts
-T
+T
To
Ts *
b
a
7
LW
1
12
11
9
+
Amplifier
9
-
+
c
b
NG 402-02
12 V ~
Sensor
Actor1 Actor2
a/b1
Door opener Relay
12
11
9
+
AC adapter
230 V ~
