ELECTROVAP MC2 STEAM BATH
Installation - Step 5
A temperature sensor located inside the hammam measures the temperature value which is
sent to the steam generator for command.
Temperature sensor
Attachement
• Bore a hole of Ø 25mm.
• Pass the sensor cable through the hole from
inside the hammam.
• Mark and drill three holes and insert pegs.
• Apply a silicon film between the Ø 60 mm disk
and the wall. Screw up the three screws.
• To prevent any steam leakage, the cable hole
can be stuffed with silicon.
Positioning
Recommended installation
Exceptional installation
If the temperature sensor is installed
on the hammam ceiling, a little water
may appear at the end of the sensor
white strainer. So we would
recommend to cut the butt end of this
strainer.
Part to cut
