ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 3 X 415V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 5,3 6 4,26 Small 25 Loop
8 8 8,5 9,3 6,60 Small 25 Straight through
10 10 10,6 11,6 8,23 Small 25 Straight through
15-2 15 15,9 17,1 12,14 Small 25 Straight through
20 20 21,2 22,7 16,11 40 large 40 Straight through
30 30 31,8 33,9 24,06 40 large 40 Split
40 40 42,4 45 31,93 2 x 40 large 40 Straight through
50 50 53 56,2 39,88 2 x 40 large 40 Split
60 60 63,6 67,3 47,76 2 x 40 large 40 Split
90 90 95,4 100,8 71,53 3 x 40 large 40 Split
MC2 Steam Bath Generator in 3 X 400V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 5,5 6,2 4,24 Small 25 Loop
8 8 8,8 9,7 6,63 Small 25 Straight through
10 10 11 12 8,21 Small 25 Straight through
15-2 15 16,5 17,8 12,18 Small 25
Straight
through
20 20 22 23,5 16,07 40 large 40 Straight through
30 30 33 35,1 24,01 40 large 40 Split
30 HC 33 36,3 38,6 26,42 40 large 40 Split
40 40 44 46,7 31,94 2 x 40 large 40 Straight through
50 50 55 58,3 39,88 2 x 40 large 40 Split
60 60 66 69,8 47,74 2 x 40 large 40 Split
60 HC 66 72,6 76,8 52,56 2 x 40 large 40 Split
90 90 98,9 104,6 71,55 3 x 40 large 40 Split
90 HC 99 108,9 115,1 78,71 3 x 40 large 40 Split
