ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 3 X 600V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 3,7 4,3 4,41 Small 25 Loop
8 8 5,9 6,6 6,77 Small 25 Straight through
10 10 7,3 8,1 8,31 Small 25 Straight through
15-2 15 11 12 12,31 Small 25 Straight through
20 20 14,7 15,8 16,21 Large 40 40 Straight through
30 30 22 23,5 24,11 Large 40 40 Split
40 40 29,3 31,3 32,11 2 x Large 40 40 Straight through
50 50 36,6 39 40,01 2 x Large 40 40 Split
60 60 44 46,7 47,91 2 x Large 40 40 Split
90 90 66 69,8 71,61 3 x Large 40 40 Split
To Next Page
