ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 3 X 575V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 3,8 4,4 4,33 Small 25 Loop
8 8 6,1 6,8 6,69 Small 25 Straight through
10 10 7,6 8,4 8,26 Small 25 Straight through
15-2 15 11,5 12,5 12,29 Small 25 Straight through
20 20 15,3 16,5 16,22 40 large 40 Straight through
30 30 22,9 24,6 24,19 40 large 40 Split
40 40 30,6 32,6 32,05 2 x 40 large 40 Straight through
50 50 38,2 40,7 40,02 2 x 40 large 40 Split
60 60 45,9 48,7 47,88 2 x 40 large 40 Split
90 90 68,8 72,9 71,68 3 x 40 large 40 Split
MC2 Steam Bath Generator in 3 X 480V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 4,6 5,2 4,25 Small 25 Loop
8 8 7,3 8 6,58 Small 25 Straight through
10 10 9,2 10,1 8,27 Small 25 Straight through
15-2 15 13,7 14,9 12,22 Small 25 Straight through
20 20 18,3 19,6 16,09 40 large 40 Straight through
30 30 27,5 29,3 24,06 40 large 40 Split
40 40 36,6 38,9 31,95 2 x 40 large 40 Straight through
50 50 45,8 48,5 39,85 2 x 40 large 40 Split
60 60 55 57,7 47,37 2 x 40 large 40 Split
90 90 82,4 87 71,43 3 x 40 large 40 Split
