ELECTROVAP MC2 STEAM BATH
Installation - Step 6
MC2 Steam Bath Generator in 3 X 220V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
transformer
wiring
5 5 10 10,9 4,2 Small 25 Straight
8 8 15,8 17 6,5 Small 25 Straight
10 10 19,7 21,1 8,1 Small 25 Straight
15-2 15 29,6 31,6 12 25 large 25 Split
20 20 39,4 41,9 16 40 large 40 Split
25 30 49 52 19,8 40 large 40 Split
30 32 64,9 68,7 26,2 2 x 40 large 40 Split
40 40 78,9 83,5 31,8 2 x 40 large 40 Split
50 50 99 104,6 39,9 3 x 40 large 40 Split
60 60 119 125,7 47,9 3 x 40 large 40 Split
70 70 138 145,7 55,5 3 x 40 large 40 Split
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 3 X 208V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
transformer
wiring
5 5 9,6 10,5 4,13 Small 25 Straight
8 8 15,3 16,5 6,49 Small 25 Straight
10 10 19,1 20,5 8,07 Small 25 Straight
15-2 15 28,7 30,6 12,04 25 large 25 Split
20 20 38,2 40,6 15,98 40 large 40 Split
25 30 47,8 50,7 19,95 40 large 40 Split
30 32 62,9 66,6 26,21 2 x 40 large 40 Split
40 40 76,5 81 31,84 2 x 40 large 40 Split
50 50 95,6 101,1 39,75 3 x 40 large 40 Split
60 60 114,7 121,2 47,66 3 x 40 large 40 Split
