Devatec ELECTROVAP MC2 - Installation - Step 6: Steam Bath Control; Steam Bath Control Configuration via Dip Switch

36 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
Circuit board ref: 500102/28...
2
1
24
25
24
25
X6
Shunt entre 1 et 2
1 2 3 4
S1
ON
Sonde température
rouge
blanc
rouge
X5
15
17
16
Steam bath control
Temperature sensor
Dip-switch SW2 configuration on main
board ref:500102 for steam bath con-
trol
Red
White
Red
Bridge between 1 & 2
Connector
X104: 15-16-17
Dip Switch SW2:
This makes possible the
selection of the control
signal - See under confi-
guration).
SW2
X104
