ELECTROVAP MC2 STEAM BATH
Maintenance - Service & alerts
M1
M2
Press Select button 1 to rotate between the menus and
press the up or down buttons to enter the desired menu
50 HOURS AFTER SWITCHING ON
- A « 1st inspection see after manuel » warning message is shown on the
window.
- The unit works on.
Please refer to checklist on page 42
- This 50 hours timer cannot be suppressed nor modified.
SERVICE TIME ELAPSED (service message)
- A « CYLINDER MAINTENANCE - SEE AFTER TECH MANUAL » service message
is shown.
- The unit works on.
Maintenance to the cylinder(s) (s.a. page 47) and to the valves (s.a. pages 48-
49) should be done.
- This timer (300 H factory preset) can be adjusted (access code 2.3.4 :
« MAINTENANCE FREQUENCY (HR) » but not removed.
SERVICE TIME OVERDUE (service message)
- If the previous alert has not been cleared, a new alert « SERVICE OVERDUE /
SYSTEM OFF » is shown 100 hours thereafter.
- The humidifier is brought to a halt.
Maintenance to the cylinder(s) (s.a. page 47) and to the valves (s.a. pages 48-
49) must be done.
- This 100 H timer cannot be suppressed nor modified.
M3
M4
CONTACTOR TO REPLACE (service message)
- «10000 H REPLACE CONTACTOR» is shown after he humidifier has been running
for 10000 hours. This means that the contactor(s) has/have been trigged on and off
for 10000 hours and that its/their replacement is/are highly recommended.
- The unit works on.
- This 10000 H timer cannot be suppressed nor modified.
1 2
3
TO CARRY OUT A RESET OF MESSAGES ABOVE, FOLLOW THIS
PROCEDURE:
-Swith the unit to manual drain by pressing the manual drain button.
-Press button 3 for at least 5 seconds.
