Devatec ELECTROVAP MC2 - Dimensions and Weight; Model Dimensions and Weight Specifications

8 Pictures for illustrating purposes only
ELECTROVAP MC2 STEAM BATH
Dimensions & Weight
469
A
533,
4
B
214,5
C
300
275
262
414
D
G
357
357
G
E
414,31
E
271,5
D
402
552
275 382
521
401,69300,61
381,78275,22275,22
G
E
G
E
D
D
H
F F
F
H
H
Dimensions in mm Weight in Kg
Humidifier
Water
inlet
Steam
outlet
Steam
outlet
spacing
Drain
outlet
Drain
outlet
spacing
Empty
Opera-
ting
Model A B C D E F G H
ELMC 1 SM CYL
475 540 217 215 355 355 15 23
ELMC 1 LG CYL
550 680 272 270 410 410 22 37
ELMC 2 CYL
845 680 272 270 400 300 400 300 30 60
ELMC 3 CYL
1075 680 272 270 380 275 380 275 45 90
ELMC
1 small
cyl.
ELMC
2 cylinders
ELMC
3 cylinders
ELMC
1 large
cyl.
• SM CYL = small cylinder, LG CYL = large cylinder
