ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 3 X 380V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 5,7 6,4 4,2 Small 25 Loop
8 8 9,1 10 6,6 Small 25 Straight through
10 10 11,4 12,4 8,2 Small 25 Straight through
15-2 15 17,1 18,4 12,1 Small 25 Straight through
20 20 22,8 24,5 16,1 40 large 40 Straight through
30 30 34,3 36,5 24 40 large 40 Split
40 40 45,7 48,5 31,9 2 x 40 large 40 Straight through
50 50 57,1 60,5 39,8 2 x 40 large 40 Split
60 60 68,5 72,6 47,8 2 x 40 large 40 Split
90 90 102,8 108,7 71,5 3 x 40 large 40 Split
MC2 Steam Bath Generator in 3 X 230V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter
Transformer
wiring
5 5 9,6 10,5 4,13 Small 25 Straight through
8 8 15,3 16,5 6,49 Small 25 Straight through
10 10 19,1 20,5 8,07 Small 25 Straight through
15-2 15 28,7 30,6 12,04 25 large 25 Split
20 20 38,2 40,6 15,98 40 large 40 Split
25 25 47,8 50,7 19,95 40 large 40 Split
30 32 62,9 66,6 26,21 2 x 40 large 40 Split
40 40 76,5 81 31,84 2 x 40 large 40 Split
50 50 95,6 101,1 39,75 3 x 40 large 40 Split
60 60 114,7 121,2 47,66 3 x 40 large 40 Split
70 70 133,8 141,3 55,57 3 x 40 large 40 Split
