ELECTROVAP MC2 STEAM BATH
Installation - Step 6
ELECTRICAL TABLES
MC2 Steam Bath Generator in 2 X 220V - 50/60 Hz
ELMC
Steam production
(KG/Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW ) diameter
Transformer
wiring
5 5,00 17 18,4 4,05 Small 25 Straight through
10 10,00 34 36 7,92 25 large 25 Split
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
MC2 Steam Bath Generator in 2 X 230V - 50/60 Hz
ELMC
Steam production(KG/
Steam)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW ) diameter
Transformer
wiring
5 5,00 16,3 17,6 4,05 Small 25 Straight through
10 10,00 32,7 34,8 8,00 25 large 25 Split
