Troubleshooting
14.3.7 Misfeed at the Fusing/Exit Section
A. Detection Timing
B. Action
Type Description
Fusing/exit section
misfeed detection
• The Exit Paper Sensor (PC3) is not unblocked even after the lapse of a given
period of time after the Synchronizing Roller Sensor (PC1) has been blocked.
Paper left at the
fusing/exit section
• The Exit Paper Sensor (PC3) is blocked at timing when the Power Switch is
turned ON, the cover is opened and closed, or a paper misfeed or malfunction
is reset.
Relevant Electrical Components
Synchronizing Roller Sensor (PC1)
Exit Paper Sensor
Master Board (PWB-A)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Initial checks – – –
2 PC1 sensor check
☞ 115 PWB-A PJ17A-3 (ON)
3 PC3 sensor check
☞ 115 PWB-A PJ15A-3 (ON)
4 Replace PWB-A – – –
To Next Page
