Develop ineo 210 - (When the Optional Duplexing Document Feeder DF-605 Is Mounted); C0044: ADF Cooling Fan Failure

15. Malfunction code Field Service Ver. 1.0 Apr. 2005
136
ineo 161 ineo 210
Troubleshooting
15.3.2 C0044: ADF Cooling Fan Failure
(When the optional Duplexing Document Feeder DF-605 is mounted)
A. Detection Timing
B. Action
Trouble Code Description
C0044
• The ADF Fan Motor Lock signal remains set to H for a set period of time while
the EDH Fan Motor is turning.
Relevant Electrical Components
Cooling Fan Motor (M3-ADF) Main Control Board (PBA-CONT)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1
Check the motor connectors for
paper connection, and correct as
necessary.
–– –
2
Check the fan for possible overload,
and correct as necessary.
–– –
3 M3-ADF operation check.
☞ 117
PBA-CONT CN9CONT-2
(REM)
E-5 (DF-605)
4 Replace PBA-CONT. – – –
