Field Service Ver. 1.0 Apr. 2005 15. Malfunction code
147
ineo 161
ineo 210
Troubleshooting
15.3.17 C1200: Faulty ASIC/Memory
A. Detection Timing
B. Action
Trouble Code Description
C1200
ASIC/memory (for image and control) fault
• A write or read error occurs with SRAM on the Control Board (PWB-C/C).
Relevant Electrical Components
Control Board (PWB-C/C)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Turn OFF and ON the Power Switch. – – –
2
Check memory on PWB-C/C for con-
nection and correct as necessary.
–– –
3 Change PWB-C/C. – – –
To Next Page
