Develop ineo 210 - Printer Section: Periodically Uneven Image

Field Service Ver. 1.0 Apr. 2005 17. Image quality problem
177
ineo 161 ineo 210
Troubleshooting
17.2.23 Printer Section: Periodically uneven image
A. Typical Faulty Images
B. Troubleshooting Procedure
4011T528AA
Step Check Result Action
1 IU is securely fastened using the dedicated fixing screws. NO • Secure in position.
2
PH Unit is securely fastened using the dedicated fixing
screws.
NO • Secure in position.
3 IU drive mechanism is dirty or damaged. YES • Clean or change.
4
PC Drum surfaces in contact with Ds Collars and drive
mechanism are dirty, scratchy, deformed, or worn.
YES • Clean or change.
5
Synchronizing Roller drive mechanism is dirty, scratchy,
deformed, or worn.
YES • Clean or change.
6
Fusing Unit drive mechanism is dirty, scratchy, deformed,
or worn.
YES • Clean or change.
NO
• Change Master Board
(PWB-A).
