Field Service Ver. 1.0 Apr. 2005 6. Other
41
ineo 161 ineo 210
Maintenance
3. Remove the torsion coil spring and
the Movable Guide Assy.
4. Remove four shoulder screws, two
washers, and the Fusing Roller/rt
Cover.
5. Remove two Bearings and the Fus-
ing Roller/rt.
Precautions for Installation of the
Fusing Roller/rt
• Install the right and left Bearings in
the directions shown in the photo
on the left.
4035D145AA
4035D071AB
4035D142AA
4035D521AA
