7.2. RS-232 COMMUNICATION PARAMETER [ 5
2 ]
500 Range scales can communicate at 8 bits without parity. You
Orly can programm the speed of de comunication betwen scale
and scaner. This parameter is measure in (Bd).
1. Make sure the scale is a MASTER.
2. Press the MENU (2 seconds) 5
2 keys.
3. Select 1.Transmission speed.
4. Pressing C you can select one of the 7 values available.
5. Press ∗
∗∗
∗
6. Press MENU (2 seconds) to quit the programming menu.
7.3. OPERATIONS WITH PC [ 5 3 ]
Using one of the DIBAL scales’ communication programs for
working under commonly used operating systems (MS-DOS, MS-
WINDOWS, UNIX,...), you can use the PC to do all the tasks
related to set-up as well as obtain all the data concerning the
transactions carried out by the scales for their subsequent
computer processing.
You can also make a back-up copy of the scale’s data (backup)
and load data from the scale (restore) with the aid of the LBS
program.
The following are the programs available:
UTILITY SCALE TYPE
OPERATING
SYSTEM
DIBALCOM
Communications Driver All
Windows 9X, NT,
XP, Me
DIBAL RMS
Scale configuration
Store management
All
Windows 9X, NT,
XP, Me
DIBAL LBS
Back-up copy
Loading data
All
Windows 9X, NT,
XP, Me
When operating, the DIBAL RMS program must always be
accompanied by the application DIBALCOM, as the latter
provides the computer with the necessary resources to enable the
communications port (COM1 or COM2 or COMX) and set up
communication with the scale.
7.3.1.Send end of day with totals clearance [ 5 3 1]
This operation allows you to forward the data stored in the scale
to the computer for their subsequent processing by a suitable
program like DIBAL RMS.
In addition, the totals accumulated in the different memories
throughout the day will be cleared to zero.
5. Press the MENU (2 seconds) 5
3 1 keys.
6. To do so, press the ∗
∗∗
∗ key 4 times.
7. Then, press MENU (2 seconds) to quit the programming
menu.
