Digi IX14 User Manual

System administration Create a Virtual LAN (VLAN) route
IX14 User Guide
312
Required configuration items
n
Device to be assigned to the VLAN.
n
The VLANID. The TCP header uses the VLAN ID to identify the destination VLAN for the packet.
To create a VLAN:
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Virtual LAN.
4. Type a name for the VLAN and click .
5. Select the Device.
6. Type or select a unique numeric ID for the VLANID.
7. Click Apply to save the configuration and apply the change.
Command line
1. Log into the IX14 command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
