Diagnostics
Configure
syslog
servers
IX14
User
Guide
676
Configure
syslog
servers
You
can
configure
remote
syslog
servers
for
storing
event
and
system
logs.



WebUI
1.
Log
into
the
IX14
WebUI
as
a
user
with
full
Admin
access
rights.
2.
On
the
menu,
click
System
.
Under
Configuration
,
click
Device
Configuration
.
The
Configuration
window
is
displayed.
3.
Click
System
>
Log
.
675
