Services Location information
IX14 User Guide
373
8. Set the protocol type for the messages. Allowed values are taip or nmea; the default is taip:
(config service location forward 0)> type nmea
(config service location forward 0)>
n
(Optional) If the protocol type is set to nmea, configure a Talker ID.
The talker IDis a two-character prefix in the NMEAmessage that identifies the source
type. The talker ID set here will override the talker ID from all sources, and all
forwarded sentences will use the configured ID.
a. Use the ? to determine available talker IDs:
(config service location forward 0)> talker_id ?
Talker ID: Setting a talker ID will override the talker ID from
all remote
sources, and all forwarded sentences from remote sources will
use the configured
ID.
Format:
Default
GA
GB
GI
GL
GN
GP
GQ
Default value: Default
Current value: Default
(config service location forward 0)>
b. Set the talker ID:
(config service location forward 0)> talker_id value
(config service location forward 0)>
The default setting is Default, which means that the talker ID provided by the source
will be used.
9. (Optional) Set the text to prepend to the forwarded message. Two variables can be included in
the prepended text:
n
%s: Includes the IX14 device's serial number in the prepended text.
n
%v: Includes the vehicle ID in the prepended text.
(config service location forward 0)> prepend __|%s|__|%v|__
(config service location forward 0)>
10. (Optional) Set the vehicle ID.
Allowed value is a four digit alphanumerical string (for example, 01A3 or 1234). If no vehicle ID
is configured, this setting defaults to 0000.
