Monitoring Configure NetFlow Probe
IX14 User Guide
524
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Monitoring > NetFlow probe.
4. Enable NetFlow probe.
5. Protocol version: Select the Protocol version. Available options are:
n
NetFlow v5—Supports IPv4 only.
n
NetFlow v9—Supports IPv4 and IPv6.
n
NetFlow v10 (IPFIX)—Supports both IPv4 and IPv6 and includes IP Flow Information
Export (IPFIX).
The default is NetFlow v10 (IPFIX).
6. Enable Flow sampler by selecting a sampling technique. Flow sampling can reduce flow
processing and transmission overhead by providing a representative subset of all flows.
Available options are:
n
None—No flow sampling method is used. Each flow is accounted.
n
Deterministic—Selects every nth flow, where n is the value of Flow sampler
population.
