Digi IX14

Virtual Private Networks (VPN) IPsec
IX14 User Guide
553
(config vpn ipsec tunnel ipsec_example nat 0)> dst value
(config vpn ipsec tunnel ipsec_example nat 0)>
18. Configure policies that define the network traffic that will be encapsulated by this tunnel:
a. Change to the root of the configuration schema:
(config vpn ipsec tunnel ipsec_example nat 0)> ...
(config)>
b. Add a policy:
(config)> add vpn ipsec tunnel ipsec_example policy end
(config vpn ipsec tunnel ipsec_example policy 0)>
c. Set the type of local traffic selector:
(config vpn ipsec tunnel ipsec_example policy 0)> local type value
(config vpn ipsec tunnel ipsec_example policy 0)>
where value is one of:
n
address: The address of a local network interface.
Set the address:
i. Use the ? to determine available interfaces:
(config vpn ipsec tunnel ipsec_example policy 0)> local
address ?
Address: The local network interface to use the address of.
This field must be set when 'Type' is set to 'Address'.
Format:
defaultip
defaultlinklocal
lan
loopback
modem
Current value:
(config vpn ipsec tunnel ipsec_example policy 0)> local
address
ii. Set the interface. For example:
(config vpn ipsec tunnel ipsec_example policy 0)> local
address LAN
(config vpn ipsec tunnel ipsec_example policy 0)>
