Digi IX14 User Manual

Virtual Private Networks (VPN) IPsec
IX14 User Guide
565
For example, to set timeout to ten minutes, enter either 10m or 600s:
(config vpn ipsec tunnel ipsec_example)> surelink timeout 600s
(config vpn ipsec tunnel ipsec_example)>
The default is 15 seconds.
11. Configure test targets:
a. Add a test target:
(config vpn ipsec tunnel ipsec_example)> add surelink target end
(config vpn ipsec tunnel ipsec_example surelink target 0)>
b. Set the test type:
(config vpn ipsec tunnel ipsec_example surelink target 0)> test value
(config vpn ipsec tunnel ipsec_example surelink target 0)>
where value is one of:
n
ping: Tests connectivity by sending an ICMP echo request to a specified hostname
or IP address.
l
Specify the hostname or IP address:
(config vpn ipsec tunnel ipsec_example surelink target 0)>
ping_host host
(config vpn ipsec tunnel ipsec_example surelink target 0)>
l
(Optional) Set the size, in bytes, of the ping packet:
(config vpn ipsec tunnel ipsec_example surelink target 0)>
ping_size [num]
(config vpn ipsec tunnel ipsec_example surelink target 0)>
n
dns: Tests connectivity by sending a DNS query to the specified DNS server.
l
Specify the DNS server. Allowed value is the IP address of the DNS server.
(config vpn ipsec tunnel ipsec_example surelink target 0)>
dns_server ip_address
(config vpn ipsec tunnel ipsec_example surelink target 0)>
n
dns_configured: Tests connectivity by sending a DNS query to the DNS servers
configured for this interface.
n
http: Tests connectivity by sending an HTTP or HTTPS GET request to the specified
URL.
l
Specify the url:
(config vpn ipsec tunnel ipsec_example surelink target 0)>
http_url value
(config vpn ipsec tunnel ipsec_example surelink target 0)>
where value uses the format http[s]://hostname/[path]
