Digi IX14

Virtual Private Networks (VPN) L2TP
IX14 User Guide
636
Required configuration items
n
For L2TP access concentrators:
l
The hostname or IP address of the L2TP network server.
l
The firewall zone for the tunnel.
n
For L2TP network servers:
l
The IP address of the L2TP access concentrator.
l
The local IP address assigned to the L2TP virtual network interface.
l
The IP address assigned to the remote peer.
l
The firewall zone for the tunnel.
Additional configuration items
n
The UDP port that L2TP servers will listen on, if other than the deafult of 1701.
n
Access control for the L2TPtunnel.
n
For L2TP access concentrators:
l
L2TP network server port.
l
The username and password of the L2TP server.
l
The metric for the tunnel.
l
Enable custom PPP configuration options for the tunnel.
o
Whether to override the default configuration and only use the custom options.
o
Optional configuration data in the format of a pppd options file.
l
SureLink options for the tunnel.
n
For L2TP network servers:
l
The Authentication method.
l
The metric for the tunnel.
l
Enable custom PPP configuration options for the tunnel.
o
Whether to override the default configuration and only use the custom options.
o
Optional configuration data in the format of a pppd options file.
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
