Digi XBEE-PRO S3B Manual

XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 110
XBee-PRO XSC Command Reference Table
TableA‐03. ATCommands(TheRFModuleexpectsnumericalvaluesinhexadecimal.“d”denotesdecimalequivalent.)
AT
Command
Binary
Command
AT Command Name Range Command Category
# Bytes
Returned
Factory
Default
*AM 0x3A (58d) Auto-set MY - Networking & Security - -
AT 0x05 (5d) Guard Time After 0x02 – 0xFFFF [x 100 msec] Command Mode Options 2 0x0A (10d)
BD 0x15 (21d) Interface Data Rate
Standard baud rates:
0 – 6
Non-standard baud rates:
0x7D – 0xFFFF
Serial Interfacing 2 0x03 9600bps
BT 0x04 (4d) Guard Time Before 2 – 0xFFFF [x 100 msec] Command Mode Options 2 0x0A (10d)
CC 0x13 (19d) Command Sequence Character 0x20 – 0x7F Command Mode Options 1 0x2B (“+”)
CD 0x28 (40d) DO3 Configuration 0 - 4 Serial Interfacing 1 0
CN 0x09 (9d) Exit AT Command Mode - Command Mode Options - -
CS 0x1F (31d) DO2 Configuration 0 – 4 Serial Interfacing 1 0
CT 0x06 (6d) Command Mode Timeout 0x02 – 0xFFFF [x 100 msec] Command Mode Options 2 0xC8 (200d)
DT 0x00 (0d) Destination Address 0 – 0xFFFF Networking 2 0
E0 0x0A (10d) Echo Off - Command Mode Options - -
E1 0x0B (11d) Echo On - Command Mode Options - -
ER 0x0F (15d) Receive Error Count 0 – 0xFFFF Diagnostics 2 0
FH 0x0D (13d) Force Wake-up Initializer - Sleep (Low Power) - -
FL 0x07 (7d) Software Flow Control 0 – 1 Serial Interfacing 1 0
FR N/A Forces the module to Reset (Special)
FT 0x24 (36d) Flow Control Threshold 0 – (DI buffer – 0x11) [bytes] Serial Interfacing 2 varies
GD 0x10 (16d) Receive Good Count 0 – 0xFFFF Diagnostics 2 0
HP 0x11 (17d) Hopping Channel 0 – 6 Networking 1 0
HT 0x03 (3d) Time before Wake-up Initializer 0 – 0xFFFF [x 100 msec] Sleep (Low Power) 2 0xFFFF
ID 0x27 (39d) Module VID
User set table: 0x10 - 0x7FFF
Read-only: 0x8000 – 0xFFFF
Networking 2 -
LH 0x0C (12d) Wake-up Initializer Timer 0 – 0xFF [x 100 msec] Sleep (Low Power) 1 1
MD 0x32 (50d) RF Mode 0 – 4 Networking & Security 1 0
MK 0x12 (18d) Address Mask 0 – 0xFFFF Networking 2 0xFFFF
*MY 0x2A (42d) Source Address 0 – 0xFFFF Networking & Security 2 0xFFFF
NB 0x23 (35d) Parity 0 – 5 Serial Interfacing 1 0
PC 0x1E (30d) Power-up Mode 0 – 1 Command Mode Options 1 0
*PK 0x29 (41d) RF Packet Size 0 - 0x100 [bytes] Serial Interfacing 2 0x40 (64d)
*PL 0x3c (60d) RF Power Level 0-4 (Special) 1 4
PW 0x1D (29d) Pin Wake-up 0 – 1 Sleep (Low Power) 1 0
*RB 0x20 (32d) Packetization Threshold 0 - 0x100 [bytes] Serial Interfacing 2 0x01
RE 0x0E (14d) Restore Defaults - (Special) - -
RN 0x19 (25d) Delay Slots 0 – 0xFF [slots] Networking 1 0
RO 0x21 (33d) Packetization Timeout 0 – 0xFFFF [x 200 µsec] Serial Interfacing 2 0
RP 0x22 (34d) RSSI PWM Timer 0 - 0x7F [x 100 msec] Diagnostics 1 0
RR 0x18 (24d) Retries 0 – 0xFF Networking 1 0
RS 0x1C (28d) RSSI 0x06 – 0x36 [read-only] Diagnostics 1 -
RT 0x16 (22d) DI2 Configuration 0 - 2 Serial Interfacing 1 0
*RZ 0x2C (44d) DI Buffer Size [read-only] Diagnostics - -
SB 0x36 (54d) Stop Bits 0 - 1 Serial Interfacing 1 0
SH 0x25 (37d) Serial Number High 0 – 0xFFFF [read-only] Diagnostics 2 -
SL 0x26 (38d) Serial Number Low 0 – 0xFFFF [read-only] Diagnostics 2 -
SM 0x01 (1d) Sleep Mode 0, 1, 3 - 8 Sleep (Low Power) 1 0
ST 0x02 (2d) Time before Sleep 0x10 – 0xFFFF [x 100 msec] Sleep (Low Power) 2 0x64 (100d)
SY 0x17 (23d) Time before Initialization 0 – 0xFF [x 100 msec] Networking 1 0 (disabled)
TR 0x1B (27d) Transmit Error Count 0 – 0xFFFF Diagnostics 2 0
