XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 8
XBee-PRO 900HP Specifications
SpecificationsoftheXBee-PRO
®
900HP/XBee-PRO
®
XSCRFModule
Specification XBee
Performance
* Indoor/Urban Range
10kbps: up to 2000 ft (610m)
200kbps: up to 1000 ft (305m)
* Outdoor RF line-of-sight
Range
10kbps: up to 9 miles (15.5km)
200kbps: up to 4 miles (6.5km)
(with 2.1dB dipole antennas)
Transmit Power Output 24 dBm (250 mW) (software selectable)
RF Data Rate (High) 200 kbps
RF Data Rate (Low) 10 kbps
Serial UART interface CMOS Serial UART, baud rate stability of <1%
Serial Interface Data Rate
(software selectable)
9600-230400 baud
Receiver Sensitivity
(typical)
-101 dBm, high data rate, -110 dBm, low data rate
Power Requirements
Supply Voltage
2.1 to 3.6 VDC**
**Supply voltages of less than 3.0V may
result in reduced performance. Output
power and receiver sensitivity may be
degraded.
Transmit Current
PL=4 : 215mA typical, (290mA max)
PL=3 : 160mA typical
PL=2 : 120mA typical
PL=1 : 95mA typical
PL=0 : 60mA typical
Idle / Receive Current 29mA typical at 3.3V, (35mA max)
Sleep Current 2.5 µA (typical)
General
**Operating Frequency
Band
902 to 928 MHz (software selectable channels)
Dimensions
1.297" x 0.962" x 0.215 (3.29cm x 2.44cm x 0.546cm) Note:
Dimensions do not include connector/antenna or pin lengths
Weight 5 to 8 grams, depending on the antenna option
Operating Temperature -40º to 85º C (industrial)
Antenna Options
Integrated wire, U. FL RF connector, Reverse-polarity SMA
connector
Digital I/O 15 I/O lines,
ADC 4 10-bit analog inputs
Networking & Security
Supported Network
Topologies
Mesh, point-to-point, point-to-multipoint, peer-to-peer
Number of Channels, user
selectable channels
64 channels available
Addressing Options PAN ID, Preamble ID, and 64-bit addresses
Encryption 128 bit AES
Agency Approvals
