RX Indicator
Frame Type: (0x90)
When the module receives an RF packet, it is sent out the UART using this message type.
Example: Example: In the above example, a device with a 64-bit address of 0x0013A200
40522BAA sends a unicast data transmission to a remote device with payload "RxData". If AO=0
on the receiving device, it would send the above frame out its serial interface.
Frame Fields Offset Example Description
A
P
I
P
a
c
k
e
t
Start Delimiter 00x7E
Length
MSB 1 0x00
Number of bytes between the length and the checksum
LSB 2 0x12
Frame-specific Data
Frame Type 30x90
64-bit Source
Address
MSB 4 0x00
50x13
64-bit address of sender
60xA2
70x00
80x40
90x52
10 0x2B
LSB 11 0xAA
Reserved 12 0xFF
Reserved
13 0xFE
Receive Options 14 0x01
bit 0: Packet was acknowledged.
bit 1: Broadcasted packet.
bits 6,7:
b’01 - Point-Multipoint
b’10 - Repeater mode (directed broadcast)
b’11 - DigiMesh (not available on 10k product)
other bits should be ignored.
Received Data
15 0x52
Received RF data
16 0x78
17 0x44
18 0x61
19 0x74
20 0x61
Checksum 21 0x11 0xFF - the 8 bit sum of bytes from offset 3 to this byte.
