XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 124
RS (RSSI) Command

RT (DI2 Configuration) Command
SB (Stop Bits) Command
SH (Serial Number High) Command

Command Summary
Description
AT Command: ATRS
<Diagnostics> RS Command returns the
signal level of the last packet
received. This reading is useful for
determining range characteristics of the
modules under various conditions of
noise and distance.
Once the command is issued, the
module will return a value between 0x6
and 0x36 where 0x36 represents a very
strong signal level and 0x4 indicates
a low signal level.
Binary Command: 0x1C (28 decimal)
Parameter Range: 0x06 – 0x36 [read-
only]
Number of bytes returned: 1
Command Summary
Description
AT Command: ATRT
<Serial Interfacing> RT
command is used to
dictate the behavior of
the
DI2/RTS/CMD line. RT
Command must be
issued to enable RTS
flow control
or binary
programming.
Binary Command: 0x16 (22 decimal)
Parameter Range:0 – 2
Parameter
Value
Configuration
0 disabled
1 Enable Binary Programming
2
Enable Flow Control
Default Parameter Value: 0
Number of bytes returned: 1
Command Summary
Description
AT Command: ATSB
SB Command is used to
set/read the number of
stop bits in the data
packets.
Binary Command: 0x36 (54 decimal)
Parameter Range:0 – 1
Parameter
Value
Configuration
01 stop bits
12 stop bits
Default Parameter Value: 0
Number of bytes returned: 1
Command Summary
Description
AT Command: ATSH <Diagnostics> Read the serial number
high word of the module.
Binary Command: 0x25 (37 decimal)
Parameter Range:0 – 0xFFFF [read-only]
Number of bytes returned: 2
Related Commands: SL (Serial Number
Low)
