XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 50
Addressing Discovery/Configuration
TO
Transmit Options.
This command defines transmission options for all packets originating from this radio.
These options can be overridden on a packet-by-packet basis by using the TxOptions field
of the API TxRequest frames.
Bit Meaning Description
6, 7 Delivery method b’00 - <invalid option>.
b’01 - Point-Multipoint
b’10 - Repeater mode (directed broadcast of packets)
b’11 - DigiMesh (not available on 10k product)
5 Reserved <set this bit to 0>
4 Reserved <set this bit to 0>
3 Trace Route Enable a Trace Route on all DigiMesh API packets
2 NACK Enable a NACK messages on all DigiMesh API packets
1 Disable RD Disable Route Discovery on all DigiMesh unicasts
0 Disable ACK Disable acknowledgments on all unicasts
Example #1: Setting TO to 0x80 would cause all transmissions to be sent using
repeater mode.
Example #2: Setting TO to 0xC1 would cause all transmissions to be sent using
DigiMesh, with network acknowledgments disabled.
Bits 6 & 7 cannot be set to
DigiMesh on the 10k build.
Bits 4 & 5 must be set to 0
Bits 1, 2, & 3 cannot be set
on the 10k build
0x40
(10k product)
0xC0
(200k product)
NI
Node Identifier. A string identifier for this module. The string accepts only printable ASCII
data In AT Command Mode, the string can not start with a space. A carriage return or
comma ends the command. Command will automatically end when maximum bytes for the
string have been entered. This string is returned as part of the ATND (Network Discover)
command. This identifier is also used with the ATDN (Destination Node) command.
up to 20 byte ASCII string a space character
NT
Node Discover Timeout. The amount of time a node will spend discovering other nodes
when ND or DN is issued. This value is used to randomize the responses to alleviate
network congestion.
0x20 - 0x2EE0
[x 100 msec]
0x82 (130d)
NO
Node Discovery Options. The options value for the network discovery command. The
options bitfield value can change the behavior of the ND (network discovery) command
and/or change what optional values are returned in any received ND responses or API
node identification frames.
Options include:
0x01 = Append DD value (to ND responses or API node identification frames)
0x02 = Local device sends ND or FN response frame when ND is issued.
0x04 = Append RSSI (of the last hop for DigiMesh networks) to ND or FN responses or
API node identification frames.
0-0x07 [bitfield] 0
CI
Cluster ID. The application layer cluster ID value. This value will be used as the cluster ID
for all data transmissions. The default value 0x11 (Transparent data cluster ID)
0-0xFFFF 0x11
DE
Destination Endpoint. The application layer destination ID value. This value will be used
as the destination endpoint for all data transmissions. The default value (0xE8) is the Digi
data endpoint.
0-0xFF 0xE8
SE
Source Endpoint. The application layer source endpoint value. This value will be used as
the source endpoint for all data transmissions. The default value 0xE8 (Data endpoint) is
the Digi data endpoint
0-0xFF 0xE8
Table5‐06. AddressingDiscovery/ConfigurationCommands
AT
Command
Name and Description Parameter Range Default
AG
Aggregator Support. The AG command sends a broadcast through the network that
has the following effects on nodes which receive the broadcast:
- The receiving node will establish a DigiMesh route back to the originating node,
provided there is space in the routing table.
- The DH and DL of the receiving node will be updated to the address of the originating
node if the AG parameter matches the current DH/DL of the receiving node.
- For API-enabled modules on which DH and DL are updated, an Aggregate Addressing
Update frame will be sent out the serial port.
Note that the AG command is only available on products that support DigiMesh.
Any 64-bit number n/a
Table5‐05. AddressingCommands
AT
Command
Name and Description Parameter Range Default
