XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 83
Setting the configuration command that corresponds to a particular pin will configure the pin:
See the command table for more information. Pullup resistors for each digital input can be enabled using the
PR command.
Pin Command Parameter
Description
0 Unmonitored digital input
1
Reserved for pin-specific
alternate functionalities.
2
Analog input (A/D pins) or
PWM output (PWM pins)
3 Digital input, monitored.
4 Digital output, low.
5 Digital output, high.
7
Alternate functionalities, where
applicable.
Module Pin Names Module Pin Number Configuration Command
CD / DIO12
4P2
PWM0 / RSSI / DIO10 6 P0
PWM1 / DIO11 7 P1
DTR / SLEEP_RQ / DIO8 9 D8
AD4 / DIO4 11 D4
CTS / DIO7
12 D7
ON_SLEEP / DIO9 13 D9
ASSOC / AD5 / DIO5 15 D5
RTS / DIO6 16 D6
AD3 / DIO3 17 D3
AD2 / DIO2 18 D2
AD1 / DIO1 19 D1
AD0 / DIO0 /
CommissioningButton
20 D0
1 Sample Sets Number of sample sets in the packet. (Always set to 1.)
