1.3 Before You Start
There are certain general operating principles and terms that should be understood before continuing to use this manual.
Please read this chapter carefully before proceeding.
1.3.1 Worksurface Layout ...............................................................
Left Section
Quick Select
Screen Scroll
2nd Function & Option/All
Assignable Rotaries and Switches
Aux / Pan / Dynamics/FX Controls
Mute and Interactive LCD
Function Button
Channel Faders
ALT Input Switch
Channel Inserts A & B On/Off
Direct Out On/Off
4 Band Dynamic Parametric EQ
High and Low Pass Filters
Multiband Dynamics
Thresholds & On / Off
Hard Mute & Undo/Redo
Channel Scroll
Layer Switch
Channel Fader Banks
Right Section
Quick Select
Assignable Rotaries and Switches
Aux / Pan / Dynamics/FX Controls
Mute and Channel Select Buttons
Channel Faders
Macro Control
Headphones & Talkback
Solos
USB Port
Touch/Turn
Snapshot Control
Master Screen Assign
Assignable Master Faders
