Digifly AIR-BT - 3 Quick Reference Guide; 2.9 Reset; Symbols

AIR_Manual_506a_ENG_rev_1.pdf Page 10/96
3
QUICK REFERENCE GUIDE
3.1
SYMBOLS
Battery level
Bluetooth activated
Static icon = GPS FIX valid (GPS position available)
Blinking icon = low GPS signal (GPS position NOT available)
Flight recorder on
Volume level
Direction towards the center of the current Waypoint
Direction towards the optimized point of the current WP’s cylinder
Direction towards the optimized point of the current WP’s cylinder
Last thermal position
Wind direction (from where it is coming)
