AIR_Manual_506a_ENG_rev_1.pdf Page 95/96
ADV-SETUP PARAMETERS MENU (ADVANCED SETUP)
n Name Description Range Default Unit
1 PITO Pitot tube enable OFF/IAS/TAS OFF ----
2 SDIF Speed difference enable OFF/ON OFF ----
3 OFSP Pitot tube offset calibration 0 – 4000 0 ----
4 KIAS airspeed calibration 50 – 200 % 100 %
5 KBAR barometer calibration +/- 10.0 0.0 mB
6 GCAL AHRS calibration 0 - 4 0
7 GPOS AHRS position 0 - 1 - 2 0
8 EFF real time average glide ratio 1 - 30 3 sec
9 EFFA average glide ratio for HW calc 1 - 99 15 sec
10 POLA polar selection OFF/P1/P2/P3 OFF ----
11-12-13 P1-A P1-B P1-C polar 1 coefficients xxx ----
14-15-16 P2-A P2-B P2-C polar 2 coefficients xxx ----
17-18-19 P3-A P3-B P3-C polar 3 coefficients xxx ----
20 MCRA McCready average time 0.2 - 30 10.0 min
21 MCRE McCready equiv. average time 0.1 – 3 0.4 sec
22 WSEN wind calculator sensibility 3 – 15 5 ----
23 CORD GPS lat lon coordinates format DMM/DMS/UTM/DDD DMS ----
24 SKPW Skip Waypoint shortcut enable OFF/ON OFF ----
25 TELE telemetry output enable OFF/CAR/FL1 … FL7 OFF ----
26 BLUT bluetooth module enable OFF/ON OFF ----
VARIOMETER SETUP PARAMETERS
n Name Description Range Default Units
1 V.UP acoustic vario lift setting 0 - 2.00 00.10 m/s
2 V.PT acoustic vario pre-thermal setting 0 - 1.50 00.50 m/s
3 V.DN acoustic vario sink setting 0 - 25.00 02.50 m/s
4 PROF acoustic vario profiles FAS/STD/SFT/US1/US2/MAN MAN ----
5 STYL rhythm style tone in lift 0 - 2 1 ----
6 MODH frequency modulation in lift 1 - 30 4 ----
7 PITC tone rhythm in lift 1 - 8 4 ----
8 UPHZ base frequency in lift 500 - 1400 700 Hz
9 DWHZ base frequency in sink 350 - 1000 600 Hz
10 RVAR Acoustic vario sensitivity 1 - 20 10 ----
11 INTE integrator vario delay 5 - 60 10 sec
12 DSEL vario bar graph mode 0/1/2/3/4 0 ----
13 TECM Total energy compensation mode OFF/ON/FULL OFF ----
14 TEC Total energy compensation value 0 - 100 50 %
15 TECA Total energy compensation average 0 - 99 80 ----
16 CRUT glide detect time threshold 2 - 20 15 sec
17 THET thermal detect time threshold 1 - 30 2 sec
18 THEZ thermal tutor zoom level 1 - 100 1 ----
19 THEA thermal assist zoom level 1 - 20 5 ----
20 SIMV vario simulator ON/OFF/FULL OFF ----
21 AUTV automatic acoustic vario OFF/ON/FULL ON ----
