CREATING A NEW WAYPOINT USING THE CURRENT POSITION (MARK)
"
" function: when the GPS acquires a valid position, it is possible to save it in the instrument’s memory.
From the
page
the key; the message "Save Mark ?" is shown, press the key to
confirm or the key to cancel. The current position will be saved as a new Waypoint in the
list
(“WPT USER”) with the format nnMaaa (aaa= altitude GPS in tens of meters)
NAVIGATION TO “HOME” WAYPOINT (GOTO HOME)
Available only on the
page, it ensures that the instrument guides us back to the point where we
activated this function from.
It is particularly useful, for example, when flying at a new site without any waypoints and want to be guided to
the official landing zone (LZ). In this case, it is necessary to go to the LZ and activate this function there.
How to activate the "
" function: from the
page, with valid GPS position,
the
key, the message "Activate Home Wpt ?" is shown, press the key to confirm or to cancel.
: if navigation has been previously activated, it is necessary to deactivate it first: from the
page
the key, the message " Clear Nav ?" is shown, press the key to confirm or to cancel.
The "
" function creates a landing waypoint in the User Waypoint list (“WPT USER”) with the current
position data “HOMaaa” (aaa = GPS altitude in tens of meters) and with the icon "A" (Airfield), at the same time,
it activates the navigation to it (GOTO).
DEACTIVATING THE CURRENT NAVIGATION (CLEAR NAV)
function: to disable the active navigation,
the button, the "Clear Nav ?" message
will appear, confirm with the button or press to cancel.
Date and current time are automatically updated with GPS data when you start the instrument and will continue
updating.
To set time zone you are in, go to:
.
