45
to 99 (all right).
Route Selects the route signal path within the Chorus/Delay, and Flange/Delay Multi effects mod-
ules.The 3 settings are: 1) Chorus/Flange into Delay with feedback into the Delay 2)
Chorus/Flange into Delay with feedback into Chorus/Flange 3) Delay into Chorus/Flange
with feedback thru the Chorus/Flange.
Speed Controls the Low Frequency Oscillator (LFO) Speed of the Chorus or Flanger. Ranges
from 0.06 to 16.0 Hz.
Depth Adjusts the intensity of the Chorus or Flanger effect. Ranges from 0 to 30 milliseconds.
Feedback (Flanger) Controls how much of the flanged signal is fed back to the input of the Module.The
FDBACK Parameter is what gives flangers their distinctive voice. Flangers are capable of
both positive and negative feedback loops, so experiment to find the sound you like best.
Ranges from -99% to 99%.
WvFrm Selects which waveform the LFO follow. Options for this control include: Sine,Triangle, SP1
(Special 1), and SP2 (Special 2).
C/F: Delay Controls the delay time of the Chorus or Flanger voice. Ranges from 0 to 40 milliseconds.
Delay Time Sets the delay time for the delay tap. Ranges from 0 to 300 milliseconds.
Feedback Controls the fade time of the delay repeats. Higher settings take longer to fade out, while a
setting of zero will limit the delay to one repeat. Ranges from 0 to 99%.
TapIt Allows you to change the Delay time in real-time by tapping the TAPIT button at the tempo
you want. Delay voice percentages do not change when using this control.
Level: C/F/D Controls the overall output level of each effect block. Ranges from Off to 100%.
Pan: C/F/D Controls the stereo soundfield placement of each effect block. Ranges from -99 (all left) to
99 (all right).
WHAMMY
EFFECTS
In today’s music industry, it seems that every album on the charts, whether it be Country, Rock, Industrial, or
Alternative, are using the DigiTech Whammy technology in some shape or form.Whether it be a subtle chorus
Detune, or an all out 2 octave Whammy Dive, this thing is a definite attention getter, and first-call studio effect. At
this rate, the Whammy effect could possibly log-in as much studio time as Chet Atkins.
W
HAMMY EFFECT PARAMETERS
Whammy On/Off Turns the Whammy module on or off. When the module is turned off, the signal will only
continue to pass through the module if the dry level is turned up.
FX Level This parameter lets you select the overall FX level mix of the Whammy Effect module.
Ranges from: Off to 100%.
Dry Level This parameter lets you select the amount of Dry signal that is included in the Whammy
effect. Ranges from: Off to 100%.
Balance This parameter allows you to pan the Dry signal either to the Right or the Left in the
stereo soundfield. Ranges from Left 99 to Right 99.
Min Shift This parameter sets the minimum pedal shift level of the Whammy effect. Ranges from: -72
(6 octaves down), to 24 (2 octaves up).
Max Shift This parameter set the maximum pedal shift level of the Whammy effect. Ranges from: -72
