71
vv software version number
When yy = 00(h) User bank is selected
When yy = 01(h) Factory bank is selected
zz The Program number, 1-100 (00-63h)
dd(n) Program data
The Receive One Program procedure is used to load a program into the 2112.The number of program bytes
to be received (n) is different for each program. If the 2112 is sent a Receive One Program procedure where
the program number is not a valid RAM destination, it will be ignored.
REQUEST BULK DUMP (49h)
SYS_HEAD, 49(h), F7(h)
When a Request Bulk Dump procedure is received, the 2112 will respond with a Receive Bulk Dump proce-
dure.
RECEIVE BULK DUMP (48h)
SYS_HEAD 48(h), dd(1st)1 dd(1st)2, ... dd(nth)1, dd(nth)2, F7(h)
dd(n) Bulk Dump Data
The Receive Bulk Dump procedure is used to load all User Programs into the 2112.A software version num-
ber is imbedded in the data.
REQUEST UTILITIES SETTINGS (11h)
SYS_HEAD, 11(h), F7(h)
When a Request Utilities Settings procedure is received, the 2112 will respond with a Receive Utilities
Settings procedure.
RECEIVE UTILITIES SETTINGS (12h)
SYS_HEAD 12(h), vv(1)1, vv(1)2, vv(2)1, vv(2)2, rr1, rr2, tt1, tt2, ee1, ee2, ff1, ff2, ss1, ss2, nn1, nn2, mm1,
mm2, qq1, qq2, yy (1st)1,yy(1st)2, zz(1st)1,zz(1st)2 ... yy(128th)1,yy(128th)2, zz(128th)1,zz(128th)2, F7(h)
vv software version number
rr MIDI Receive Channel (range = 00(h) ~ 07(h))
tt MIDI Transmit Channel (range = 00(h) ~ 07 (h)
ee Cabinet Emulator (range = 00(h) ~ 07 (h)
ff Foot Controller (range = 00(h) ~ 07(h))
ss SysEx Channel (Studio 2112 only)
nn MIDI Merge On/Off (Studio 2112 only)
mm Mono-Stereo (range = 00(h) ~ 01(h)
qq EQ mode (range = 00(h) ~ 07(h))
yy, zz Program Map Settings (MIDI Program changes 1 ~ 128 = map)
When yy = 00(h) User Bank is selected
When yy = 01(h) Factory Bank is selected
When yy = 02(h) and zz =00(h), Bypass toggle is selected
zz Program Number.
REQUEST PARAMETER VALUE (17h)
SYS_HEAD 17(h), aa1, aa2,bb1, bb2, F7(h)
