67
2112 S
PECIFICATIONS
A/D Converter: 20 bit, 64 x oversampled delta-sigma stereo
D/A Converter: 20 bit 64 x oversampled
Sampling Frequency: 44.1 kHz
Frequency Response 20~20kHz +/- 0.5 dB
DSP SECTION:
Static-Dynamic Instruction Set computer 2 (S-DISC II
®
)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 64k x 24 bits (1.4 seconds)
Static Delay Memory: 256 24-bit registers (5.8 milliseconds)
Data ALU Processing: 45.1 MIPS
Address ALU Processing: 33.8 MIPS
Multiplier Size: 24 bits x 24 bits
THD Less than 0.03 (kHz)
I
NPUT SECTION
:
Connectors: 1- 1/4" TRS Plug balanced
Nominal Level: -10 dBV, +4 dBu, software variable
Maximum Level: +18 dBu
Impedance: 10 kΩ
O
UTPUT SECTION
:
Connectors: 2- 1/4" TRS Plug balanced,
Nominal Level: -10dBV, +4 dBu switchable
Maximum Level: +18 dBu
Impedance: 470 Ω
Recommended Output Load: 20K Ω
GENERAL:
Frequency Response: 20 Hz. - 20kHz. ±3 dB
S/N ratio: Greater than 91 dB; ref =max signal, 22 kHz measurement bandwidth, unweighted
96dB Max signal “A” Unweighted
Total Harmonic Distortion Less than 0.03% (1 kHz)
Midi In, Out/Thru
MEMORY CAPACITY:
Factory: 124 Programs
User: 100 Programs
POWER REQUIREMENTS:
US and Canada: 120 VAC, 60 Hz
Japan: 100 VAC, 50/60 Hz
Europe: 230 VAC, 50 Hz
UK: 240 VAC, 50 Hz
Power Consumption: 28 watts
Dimensions: 19" (482 mm) W x 3.50" (88 mm) H x 9.25" (234 mm) D
Net Weight: 10.60 lbs (4.80 kg.)
Shipping Weight: 13.35 lbs. (6.05 kg.)
