USE THE INDICATOR AS WEIGHT REPEATER
47
9 USE THE INDICATOR AS WEIGHT REPEATER
If it has purchased the indicator in the repeater version, the indicator can play a function in the choice
between the following:
- UNIVERSAL SINGLE SCALE WEIGHT REPEATER
- WEIGHT REPEATER MULTISCALE
The operating mode is selectable in the Setup environment ( ).
9.1 UNIVERSAL SINGLE SCALE REPEATER ()
Through this way of operation it is possible to use the indicator to repeat the weight of any scale, but
without the possibility to repeat keys.
At the start-up the indicator enter in waiting for data; if it not receive a string of successful communication,
the communication parameters results wrong, or does not receive any character, it remains in the test
condition, so with all the central segments on.
When it has identified the serial stringo f the connected instrument, the indicator repeats the display’s data
or the weight’s string of the instrument which is connected to.
WARNING:
- Keys pressed in the REPEATER are not repente on the TRANSMITTER and vice versa.
- The indicator provides as a simple weight repeater: is only enabled the C-ON/OFF key to turn on/off the
instrument.
9.2 MONO-MULTISCALE REPEATER ()
Through this operating mode it is possible to use the indicator to repeat the weight of one or more scales,
with the possibility to repeat even keys, functions, prints and store the weight in memory (if present).
The system can be composed of one or more indicators (up to 32, called SLAVES), having one or more
weighing systems, which communicate with another indicator (called MASTER) that act as weight repeater.
On it can be displayed (and printed if the printer is planned) the weight of each single scale or the sum of
the weight detected by the single scales.
SLAVES can be connected to up to 4 platforms.
