USE THE INDICATOR AS WEIGHT REPEATER
49
9.2.3 SLAVE SELECTION / SUM
If more slaves are configured, it is possible to toggle the viewing on a single SLAVE or on the SUM.
With the 5-key indicator
- Pressing the MODE key it toggles SLAVE in SLAVE in order of address: the display shows “”
(where n is the number of the SLAVE), then it displays the weight transmitted by the selected SLAVE.
- holding down the MODE key for a few seconds, it is possible to see the sum of the weights on all the
detected scales: the display shows “”, then the sum of the net weight on the detected scales.
With the 17-key indicator, the operation is similar to the previous one, but you can directly select the
desired SLAVE, if the MASTER is in sum viewing:
- if they are configured from 2 to 9 slaves it is possible to directly select the desired SLAVE through the
relative numeric key on the keyboard (E.G: MASTER  press key 1  SLAVE 1 selection).
- If 10 or more slaves are configured, it is possible to directly select the desired SLAVE by entering the
corresponding number using the numeric keys and then pressing the ENTER/PRINT key (E.G:
MASTER  press key 1  press key 0  press ENTER/PRINT  SLAVE 10 selection).
If the SLAVE is connected to multiple platforms, once you have selected the desired SLAVE, it is also
possible to select the desired SLAVE’S platform by pressing the numeric keys.
9.2.4 TARE EXECUTION IN SUM MODE
It is possible to execute the manual or the semi-automatic tare of the sum (in both cases the PT symbol on
the LCD display is activated).
9.2.5 EXECUTION OF THE PRINTS
When the MASTER repeat a single SLAVE, it is possible to make the print on both or on the one provided of
a printer. Methods and printed data depends on the operating mode selected in the SLAVE.
Se nel sistema sono presenti più di uno SLAVE, il numero dello SLAVE dal quale proviene il peso verrà
aggiunto sulle singole stampe direzionate sul MASTER.
When the MASTER repeats the sum of more SLAVE, it is possible to print on it weights of individual SLAVE,
the sum of the tare and the difference, if on it there is a printer. Moreover, even in this case it is possible to
print the header, the receipt number and the date / time, if programmed.
9.2.6 WEIGHS LIST OPTIONS (STANDARD IN THE MODEL DFWPM10USB)
If the MASTER provides it, it is possible to save the weight in a list that can contain up to 487 weighings and
that can be read to PC or printed at a later time.
The print function are disabled in this case.
The data stored in the weighs list, include:
- progressive number of the weigh
