WIRING AND POWER
9
3 WIRING AND POWER
3.1 CONNECTING THE WEIGHING SYSTEM
The connection of the system depends on the weighing platform and indicator model purchased
If required, connect the cable from the weighing system to the connector on the cable from the indicator of
weight or place directly on it.
For the operation of the platform, refer to the corresponding manual.
3.2 POWER SUPPLY
The connection to the mains supply depends on the type of power supplied (refer to the table in paragraph
2)
For connection to the mains supply must be complied with safety standard including the use of a “clean”
line and free of noise interference from other electronic devices.
If the instrument is powered properly, the light turn on on power-on LED on the front panel.
In addition, if there is an internal rechargeable battery, it will be reacharged.
3.2.1 INTERNAL POWER CONNECTION 110-240 VAC
Plug the cable from the indicator to the network (110-240 Vac).
