FRONT PANEL KEYS AND INDICATORS
16
ENTER / PRINT
- It carries out a specific function of the operating mode set in the set-up environment.
- In the numeric input phase, it confirms the entry made.
- In the SET-UP, it allows to enter a step or to confirm a parameter within a step.
- It transmits the data from the serial port dedicated to the printer.
C / i
- It turns the instrument on and off.
- In the numeric input phase, it quickly zeros the present value.
- In the SET-UP, it allows to exit a step without confirming the change made;
in the 5-key indicator:
- Allows viewing the scale’s metric information: capacity, division, minimum weigh for
each configured range.
5.1.1 NUMERIC INPUT WITH THE 5-KEY KEYPAD
With the 5-key keypad, you can enter a numeric value in the input stage with the following keys:
ZERO decreases the blinking digit.
TARE increases the blinking digit.
MODE select the digit to be modified (blinking); the scrolling of the digits takes place from left to
right.
C if pressed for an instant it quickly zeros the present value; if pressed at length it allows to
return to weighing without saving the changes made.
ENTER Confirm the setting and leave the input.
