5 FRONT PANEL KEYS AND INDICATORS
The front panel of the indicator is designed for quick and simple weighing applications. It consists of a
display with 6 digits, 25 mm in height, 7 LED indicators (depending on the model), and a 5-key water-proof
film keyboard.
LEDS, if present, will be active during weighing to indicate the operative status (see paragraph “WARNING
LAMPS”).
If the indicator has an LCD display, while weighing, various multifunction symbols indicating the functioning
status will turn on (see section “SYMBOLS ON THE LCD DISPLAY”).
5.1 FRONT PANEL KEYS AND INDICATORS (5 key version)
DFW LCD DISPLAY VERSION
