Page 105
AIM 2 Operation Manual
Updating the Meter
Chapter 10
Overview
You can update your AIM as new features become available via the Internet or USB ash
drive.
You can update the meter rmware without plugging the AIM into a power outlet, as long as
the battery icon on the display shows at least two remaining bars of power. If the battery icon
shows less than two bars of power, the meter must be plugged into a power outlet using the
AC power adapter.
To view the current AIM rmware version, press CONFIG to go to the CONFIGURATION
screen. Then highlight Firmware Versions and press SELECT.
Updating the Firmware
1. Press CONFIG to go to the CONFIGURATION screen.
2. Select Firmware Upgrade and press SELECT
to go to the FIRMWARE UPGRADE screen.
3. The FIRMWARE UPGRADE screens appears
with the following options:
• Select update from the Internet
• Select update from USB
To Next Page
