Page 107
AIM 2 Operation Manual
Appendix
Chapter 11
Specications
Frequency Range 250 MHz to 2150 MHz
Signal Level Range -10 to -69 dBmV
RF Input Connector Replaceable “F” connector (2)
Input Impedance 75 Ω
LNB Power Supply 13 Volts / 18 Volts
SWiM Power Supply 21 Volts
Communications
Wi-Fi (802.11 b,g and n, 2.4 GHz); Bluetooth (4.0 and BLE dual mode); and Gigabit
Ethernet
USB flash drive (Linux format only)
Battery 6-cell, 10.8 Volt, 4.4 AH rechargeable Li-ion
Operating Temperature -29° to +52° C (-20° to 126° F)
Storage Temperature -40° to +65° C (-40° to 149° F)
Battery Charging
Temperature
5° to 37° C (-41° to 99° F)
Display 240 x 160 pixel, backlit LCD
Weight 1225 grams (2.54 lbs)
Dimensions (H x W x D) 350 x 126 x 61 mm (13.7 x 4.9 x 2.4 in)
