Page 15
AIM 2 Operation Manual
Getting to Know Your Meter
Chapter 3
Overview
Before using your instrument, take a few minutes to familiarize yourself with the instrument,
its basic conventions, and its navigational tools. This section provides a brief overview of the
instrument’s features, buttons, and controls.
Equipment Supplied with the AIM
The AIM comes with the following:
• AIM meter
• Carrying case (with shoulder strap and hand strap)
• 100 – 240 VAC power adapter
• 12 VDC vehicle power adapter
• 25 Ω cable test load
• 2 GB USB ash drive (containing AIM Operator Manual)
Replacement Parts
The following replacement parts are available for the AIM:
Part Number Description
2131596000 Carrying case (with shoulder strap and storage pocket)
0610177000 100 – 240 VAC power adapter
2072097000B 12 VDC vehicle power adapter
0090070000 Battery pack
0200690000 “F” connector
2011379000 25 Ω cable test load
0930157003 2 GB USB flash drive (containing AIM Operator Manual)
