Page 22
AIM 2 Operation Manual
Battery Replacement
If necessary, you can replace the AIM’s battery. To obtain a new battery, contact Trilithic.
See the Spare Parts List earlier in the manual.
You also can return your AIM to Trilithic Customer Service and request that the battery be
replaced. See the Return Policy section.
1. Using a Phillips-head screwdriver, loosen and
remove the 2 screws from the battery door as
shown here.
2. Remove the battery cover by lifting up on the top of
the door.
Make sure the AIM is turned off and is not connected to a
power source before you remove and replace the battery.
3. Remove the battery pack.
4. Remove the battery connector by pulling straight up.
Battery pack
Battery
connector
