Page 52
AIM 2 Operation Manual
The table below indicates which tasks need to be performed for each ODU. When an
installation includes two ODUs, you must perform the installation tasks for each ODU. The
AIM Install feature guides you through the tasks based on the selected ODU. When using
the AIM to align an ODU, refer to the appropriate sections for assistance:
Task A. Installation Setup
Task B. Coarse Azimuth Adjustment
Task C. Coarse Elevation Adjustment
Task D. Tilt Adjustment (95°, 3-LNB, Slimline-5, and Slimline-5S (SWiM) ODUs
Only)
Task E. Fine Elevation Adjustment (Slimline ODUs Only)
Task F. Fine Azimuth Adjustment (Slimline ODUs Only)
ODU Installation Tasks
