Page 83
AIM 2 Operation Manual
10. If you want to set the SWiM (or DSWiM)
channel for the transponder survey, do the
following:
• Press OPTIONS.
• On the TR SURVEY OPTIONS screen,
highlight Set SWiM Ch. (Connect
SWiM).
• Highlight the desired channel and press
SELECT to go to the TRANSPONDER
SURVEY screen.
11. Press RUN TR SURVEY to start the test. The screen indicates each orbital slot and
transponder as they are scanned.
12. When the scan test is complete, press VIEW to go to the TR SURVEY RESULTS
screen.
To add a note about the transponder survey, such as details
about where the survey is being performed, press NOTES.
To test spot transponders in the survey, press WITH SPOTS.
To remove spot transponders from the survey, press
WITHOUT SPOTS.
