AiStarter User Guide 3Feature Description
IssueV1.0.3（2018-09-01） AiStarter User Guide Copyright © Yuejiang Technology Co., Ltd
7
No.
Description
3
User-defined
User can set function in Mixly or Arduino IDE environment
4
User-defined
User can set function in Mixly or Arduino IDE environment
3.1.4 LED
The end of AiStarter controller integrates four LED indicators, as shown in Figure 3.1, the
detail descriptions are shown in Table 3.2.
Table 3.2 LED indicators description
No.
Color
description
A
Blue
User-defined
User can set function in Mixly or Arduino IDE environment
B
Red
 Off: Indicate that the AiStarter is uncharged.
 Steady Red is always on: Indicates that the AiStarter is charging.
C
Red
 Off: Indicates that the AiStarter battery voltage is normal.
 Steady Red: Indicates that the AiStarter battery has a low voltage
D
Blue
User-defined
User can set function in Mixly or Arduino IDE environment
3.1.5 USB
AiStarter intergrates USB download function, you can download program to AiStarter by
USB, and make AiStarter run by program. Meanwhile, USB charging function are supported by
Aistarter, you can charge AiStarter by connecting AiStarter to computer with USB cable when
AiStarter battery has a low voltage.
Operating systems are supported by USB driver:
 Win7
 Win8
 Win10
NOTICE
When you install Mixly or Arduino IDE, the Arduino USB drive will be installed
automatically. After connecting AiStarter to computer by USB cable and starting
computer, you can find the corresponding COM port on device manager, as shown in
Figure 3.2. If the corresponding COM port is not found, you need to install Arduino
